| Item |
P.Pmulti |
Nylon |
Polyester |
P.E |
| DIA |
W'T(kg) |
W't(kg) |
W't(kg) |
W't(kg) |
| 2 |
0.41 |
0.49 |
0.65 |
0.43 |
| 3 |
0.91 |
1.20 |
1.39 |
0.92 |
| 4 |
1.50 |
2.00 |
2.47 |
1.72 |
| 5 |
2.40 |
3.10 |
3.86 |
2.70 |
| 6 |
3.50 |
4.50 |
5.50 |
3.60 |
| 7 |
4.80 |
6.20 |
7.55 |
4.90 |
| 8 |
6.20 |
8.10 |
9.87 |
6.40 |
| 9 |
8.00 |
10.20 |
12.50 |
8.20 |
| 10 |
10.00 |
12.70 |
15.40 |
10.00 |
| 11 |
12.00 |
15.20 |
18.60 |
12.00 |
| 12 |
14.30 |
18.20 |
22.20 |
14.80 |
| 13 |
16.70 |
20.80 |
26.10 |
16.90 |
| 14 |
19.00 |
24.70 |
30.20 |
19.60 |
| 16 |
25.00 |
32.20 |
39.50 |
25.00 |
| 18 |
31.50 |
40.90 |
50.00 |
31.30 |
| 19 |
36.00 |
44.40 |
55.70 |
35.20 |
| 20 |
42.00 |
51.00 |
66.00 |
40.20 |
| Item |
PPM DOUBLE BRAID |
N/P DOUBLE BRAID |
NYLON DOUBLE BRAID |
POLYESTER DOUBLE BRAID |
| GRAVITY |
0.91 |
1.02 |
1.14 |
1.38 |
DIA
(mm) |
PPM COVER |
NYLON COVER |
NYLON COVER |
POLYESTER COVER |
| PPM CORE |
PPM CORE |
NYLON CORE |
POLYESTER CORE |
| W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
| 20 |
42.0 |
5.8 |
51.0 |
7.6 |
51.0 |
9.3 |
66.0 |
9.7 |
| 22 |
47.0 |
6.8 |
63.0 |
9.7 |
64.0 |
10.7 |
82.0 |
11.9 |
| 24 |
58.0 |
7.7 |
73.0 |
12.0 |
71.0 |
12.7 |
99.0 |
14.6 |
| 26 |
68.0 |
9.0 |
85.0 |
13.0 |
84.0 |
15.6 |
116.0 |
17.7 |
| 28 |
79.0 |
11.0 |
99.0 |
15.0 |
103.0 |
18.0 |
132.0 |
19.3 |
| 30 |
90.0 |
13.0 |
112.0 |
18.0 |
116.0 |
21.0 |
150.0 |
21.8 |
| 32 |
106.0 |
14.0 |
129.0 |
20.0 |
129.0 |
22.0 |
174.0 |
24.8 |
| 34 |
116.0 |
16.0 |
145.0 |
22.0 |
149.0 |
27.0 |
192.0 |
27.2 |
| 36 |
133.0 |
18.0 |
162.0 |
25.0 |
169.0 |
29.0 |
217.0 |
31.2 |
| 38 |
148.0 |
20.0 |
181.0 |
27.0 |
182.0 |
32.0 |
242.0 |
32.0 |
| 40 |
165.0 |
21.0 |
201.0 |
30.0 |
208.0 |
36.0 |
267.0 |
37.2 |
| 42 |
181.0 |
23.0 |
221.0 |
34.0 |
227.0 |
39.0 |
292.0 |
40.3 |
| 44 |
198.0 |
25.0 |
242.0 |
36.0 |
249.0 |
43.0 |
320.0 |
43.9 |
| 45 |
208.0 |
26.0 |
253.0 |
37.0 |
261.0 |
44.0 |
335.0 |
45.3 |
| 48 |
236.0 |
30.0 |
287.0 |
42.0 |
294.0 |
50.0 |
387.0 |
51.8 |
| 50 |
257.0 |
32.0 |
313.0 |
48.0 |
320.0 |
54.0 |
420.0 |
56.2 |
| 52 |
277.0 |
34.0 |
338.0 |
50.0 |
345.0 |
60.0 |
454.0 |
60.5 |
| 55 |
310.0 |
39.0 |
379.0 |
56.0 |
386.0 |
66.0 |
504.0 |
68.1 |
| 56 |
321.0 |
40.0 |
393.0 |
58.0 |
399.0 |
69.0 |
522.0 |
71.4 |
| 60 |
370.0 |
45.0 |
451.0 |
67.0 |
459.0 |
78.0 |
607.0 |
81.5 |
| 64 |
416.0 |
51.0 |
512.0 |
72.0 |
521.0 |
90.0 |
686.0 |
88.9 |
| 65 |
429.0 |
53.0 |
528.0 |
74.0 |
538.0 |
93.0 |
708.0 |
93.0 |
| 70 |
505.0 |
63.0 |
614.0 |
82.0 |
624.0 |
103.0 |
819.0 |
109.0 |
| 72 |
534.0 |
68.0 |
649.0 |
93.0 |
660.0 |
109.0 |
866.0 |
115.0 |
| 75 |
577.0 |
73.0 |
703.0 |
96.0 |
723.0 |
118.0 |
939.0 |
118.0 |
| 80 |
658.0 |
82.0 |
800.0 |
123.0 |
819.0 |
138.0 |
1075.0 |
144.0 |
| 85 |
743.0 |
93.0 |
905.0 |
138.0 |
925.0 |
156.0 |
1213.0 |
162.0 |
| 90 |
833.0 |
103.0 |
1014.0 |
155.0 |
1036.0 |
175.0 |
1360.0 |
182.0 |
| 95 |
928.0 |
115.0 |
1130.0 |
173.0 |
1155.0 |
195.0 |
1516.0 |
202.0 |
| 100 |
1028.0 |
128.0 |
1252.0 |
192.0 |
1280.0 |
216.0 |
1680.0 |
225.0 |
| ITEM |
P.P/P.P MULTI |
POLYETHYLENE |
NYLON |
VINYLON |
POLYESTER |
| |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
W'T(kg) |
BL(ton) |
| 3 |
0.85 |
0.12 |
0.92 |
0.1 |
1.2 |
0.22 |
0.2 |
0.09 |
|
|
| 5 |
2.3 |
0.32 |
2.7 |
0.28 |
3.0 |
0.5 |
3.13 |
0.23 |
3.68 |
0.4 |
| 6 |
3.5 |
0.55 |
3.6 |
0.4 |
4.5 |
0.75 |
4.5 |
0.33 |
5.56 |
0.56 |
| 8 |
6.2 |
0.96 |
6.4 |
0.7 |
7.8 |
1.35 |
7.96 |
0.56 |
9.88 |
1.02 |
| 9 |
7.8 |
1.19 |
8.2 |
0.9 |
9.8 |
1.7 |
10.0 |
0.7 |
12.5 |
1.27 |
| 10 |
9.6 |
1.43 |
10.0 |
1.09 |
12.1 |
2.8 |
12.4 |
0.95 |
15.4 |
1.59 |
| 12 |
13.9 |
2.03 |
14.8 |
1.54 |
17.6 |
3.0 |
17.8 |
1.37 |
22.2 |
2.27 |
| 14 |
18.8 |
2.79 |
20.0 |
2.09 |
23.9 |
4.1 |
24.2 |
1.83 |
30.3 |
3.18 |
| 16 |
24.2 |
3.5 |
25.8 |
2.8 |
30.8 |
5.3 |
31.5 |
2.34 |
39.5 |
4.1 |
| 18 |
30.8 |
4.45 |
32.6 |
3.46 |
38.7 |
6.7 |
39.8 |
2.92 |
50.0 |
5.1 |
| 20 |
38.0 |
5.37 |
40.2 |
4.27 |
48.0 |
8.3 |
49.0 |
3.55 |
61.8 |
6.3 |
| 22 |
46.0 |
6.5 |
48.8 |
5.08 |
57.9 |
10.0 |
59.2 |
4.24 |
74.7 |
7.6 |
| 24 |
54.7 |
7.6 |
58.0 |
6.1 |
69.5 |
12.0 |
70.4 |
4.98 |
88.9 |
9.1 |
| 26 |
63.8 |
8.8 |
68.0 |
6.91 |
81.3 |
13.8 |
82.5 |
5.78 |
104.0 |
10.6 |
| 28 |
73.6 |
10.1 |
79.0 |
8.03 |
95.3 |
15.8 |
95.6 |
6.64 |
121.0 |
12.2 |
| 30 |
85.2 |
11.4 |
90.8 |
8.94 |
108.0 |
17.8 |
109.0 |
7.55 |
139.0 |
13.9 |
| 32 |
96.7 |
12.8 |
103.0 |
10.4 |
123.0 |
20.0 |
124.0 |
8.51 |
158.0 |
15.7 |
| 34 |
110.0 |
14.0 |
116.6 |
11.6 |
139.0 |
22.0 |
140.0 |
9.53 |
178.0 |
17.5 |
| 36 |
122.0 |
16.1 |
130.0 |
13.0 |
155.0 |
24.8 |
157.0 |
10.6 |
200.0 |
19.3 |
| 38 |
135.0 |
17.7 |
145.2 |
14.3 |
174.0 |
27.4 |
175.0 |
11.7 |
223.0 |
21.6 |
| 40 |
152.0 |
19.4 |
161.0 |
15.6 |
191.0 |
30.0 |
194.0 |
12.9 |
247.0 |
23.9 |
| 42 |
167.0 |
21.4 |
178.0 |
17.2 |
213.0 |
32.9 |
213.0 |
14.1 |
272.0 |
26.1 |
| 45 |
191.0 |
24.4 |
204.0 |
19.7 |
244.0 |
37.4 |
245.0 |
16.0 |
313.0 |
29.8 |
| 48 |
218.0 |
27.2 |
232.0 |
22.4 |
277.0 |
42.0 |
270.0 |
17.9 |
360.0 |
33.5 |
| 50 |
236.0 |
29.3 |
251.2 |
24.3 |
302.0 |
45.4 |
302.0 |
19.5 |
386.0 |
36.3 |
| 55 |
286.0 |
34.9 |
304.4 |
29.2 |
367.0 |
54.4 |
355.0 |
23.3 |
467.0 |
42.8 |
| 60 |
340.0 |
41.2 |
362.0 |
31.0 |
438.0 |
63.8 |
433.0 |
27.4 |
566.0 |
49.8 |
| 65 |
392.0 |
48.1 |
434.0 |
36.2 |
513.0 |
74.3 |
508.0 |
31.8 |
652.0 |
59.0 |
| 70 |
455.0 |
55.8 |
493.0 |
42.0 |
596.0 |
86.1 |
589.0 |
36.5 |
757.0 |
68.1 |
| 75 |
522.0 |
63.5 |
566.0 |
48.3 |
683.0 |
97.6 |
675.0 |
41.5 |
890.0 |
78.2 |
| 80 |
594.0 |
72.0 |
646.0 |
55.0 |
777.0 |
110.0 |
767.0 |
46.8 |
988.0 |
88.4 |
| 85 |
660.0 |
81.3 |
729.0 |
61.8 |
874.0 |
124.2 |
866.0 |
52.4 |
1,120.0 |
98.8 |
| 90 |
740.0 |
90.4 |
832.4 |
69.3 |
980.0 |
137.0 |
973.0 |
58.2 |
1,250.0 |
110.3 |
| 95 |
817.0 |
100.7 |
920.0 |
77.2 |
1,080.0 |
152.6 |
1,091.0 |
64.4 |
1,390.0 |
122.4 |
| 100 |
905.0 |
110.7 |
1,020.0 |
85.5 |
1,200.0 |
167.1 |
1,200.0 |
70.8 |
1,540.0 |
135.6 |
|
